CM Series

Compact, lightweight generators that are a cost-effective solution for all radiographic applications

Data Sheet

CM Series

Compact, lightweight generators that are a cost-effective solution for all radiographic applications

Data Sheet

Flexible Control and Customization

CM Series generators offer advanced high-quality radiographic capabilities with unmatched performance and reliability, resulting in the lowest cost of ownership over the product lifetime. This generator is suitable for DR, CR, and film-based radiographic systems and features leading-edge computer-based controls to minimize patient dose and maximize image quality while demonstrating excellent reproducibility with user-friendly operator controls.

Technical Specifications

CM Series Generator

CM Series Generator	32 kW (CM150 EA)	32 kW	40 kW	50 kW	65 kW	80 kW
Generator Type	High-frequency energy-assist	High-frequency output (maximum 400 kHz)	High-frequency output (maximum 400 kHz)	High-frequency output (maximum 400 kHz)	High-frequency output (maximum 400 kHz)	High-frequency output (maximum 400 kHz)
kVp Range	40-125 kV	40 – 125 kV	40 – 125 kV	40 – 150 kV	40 – 150 kV	40 – 150 kV
mA Range	10-500 mA	10 – 400 mA	10 – 500 mA	10 – 630 mA	10 – 800 mA	10 – 1000 mA
mAs Range	0.1-500 mAs	0.1 – 500 mAs	0.1 – 500 mAs	0.1 – 630 mAs	0.1 – 800 mAs	0.1 – 1000 mAs
Input Phase/Voltage	100-240 VAC (1 phase)	208-230 VAC (1 phase) 208-230 VAC (150 kV optional 3 phase) 400-480 VAC (150 kV optional 3 phase)	208-230 VAC (1 phase) 208-230 VAC (150 kV optional 3 phase) 400-480 VAC (150 kV optional 3 phase)	208-230 VAC (150 kV optional 3 phase) 400-480 VAC (150 kV optional 3 phase)	208-230 VAC (External transformer required 3 phase) 400-480 VAC (3 phase)	400-480 VAC (3 phase)

CM Series Generator

CM Series Generator	32 kW (CM150 EA)	32 kW	40 kW	50 kW	65 kW	80 kW
Generator Type	High-frequency energy-assist	High-frequency output (maximum 400 kHz)	High-frequency output (maximum 400 kHz)	High-frequency output (maximum 400 kHz)	High-frequency output (maximum 400 kHz)	High-frequency output (maximum 400 kHz)
kVp Range	40-125 kV	40 – 125 kV	40 – 125 kV	40 – 150 kV	40 – 150 kV	40 – 150 kV
mA Range	10-500 mA	10 – 400 mA	10 – 500 mA	10 – 630 mA	10 – 800 mA	10 – 1000 mA
mAs Range	0.1-500 mAs	0.1 – 500 mAs	0.1 – 500 mAs	0.1 – 630 mAs	0.1 – 800 mAs	0.1 – 1000 mAs
Input Phase/Voltage	100-240 VAC (1 phase)	208-230 VAC (1 phase) 208-230 VAC (150 kV optional 3 phase) 400-480 VAC (150 kV optional 3 phase)	208-230 VAC (1 phase) 208-230 VAC (150 kV optional 3 phase) 400-480 VAC (150 kV optional 3 phase)	208-230 VAC (150 kV optional 3 phase) 400-480 VAC (150 kV optional 3 phase)	208-230 VAC (External transformer required 3 phase) 400-480 VAC (3 phase)	400-480 VAC (3 phase)
